ASL 650-T8 Floor Grinding Machine
ASL 650-T8 Floor Grinding Machine
Regular price
$9,424.99 USD
Regular price
Sale price
$9,424.99 USD
Unit price
/
per
Shipping calculated at checkout.
Financing Opportunities Available
The aluminum alloy gearbox and planetary gear driver are capable of reaching a remarkable flat grind to produce smooth surfaces as well as a powerful repairing scratches function. There is a folding handle and split body design for a more convenient way to carry and transport the machine. The automatic leveling system has excellent flexibility to evenly touch the floor and perfectly balance the machine. Through the integrated system of the suction port, the machine grind and polish wet or dry. There are four different models available for this 25.5 inch grinder.
Description
| MODEL | A1 | A2 | B1 | B2 |
| VOLTAGE | 380-440v | 3 Phase | 208-240v | 1 or 3 Phase | 380-440v | 3 Phase | 208-240v | 1 or 3 Phase |
| CURRENT | 26A | 40A | 26A | 40A |
| MOTOR | 10 HP (7.5 KW) | 10 HP (7.5 KW) | 10 HP (7.5 KW) | 10 HP (7.5 KW) |
| INVERTER | 10 HP (7.5 KW) | 15 HP (11 KW) | 15 HP (11 KW) | 15 HP (11 KW) |
| FREQUENCY | 50/60 HZ | 50/60 HZ | 50/60 HZ | 50/60 HZ |
| DISK SPEED | 300-1800 RPM | 300-1600 RPM | 300-1800 RPM | 300-1600 RPM |
| GRINDING WIDTH | 25 in (650 mm) | 25 in (650 mm) | 25 in (650 mm) | 25 in (650 mm) |
| DISC DIAMETER | 10 in X 3 (250 mm x 3) | 10 in X 3 (250 mm x 3) | 10 in X 4 (250 mm x 4) | 10 in X 4 (250 mm x 4) |
| WATER TANK | 8 Gallons (30 L) | 8 Gallons (30 L) | 8 Gallons (30 L) | 8 Gallons (30 L) |
| WEIGHT | 620 lbs (281 kg) | 620 lbs (281 kg) | 573 lbs (270 kg) | 573 lbs (270 kg) |
| DIMENSION | 38" x 26" x 37" (970 x 650 x 950 mm) | 38" x 26" x 37" (970 x 650 x 950 mm) | 38" x 26" x 37" (970 x 650 x 950 mm) | 38" x 26" x 37" (970 x 650 x 950 mm) |
